Secure the bracket in the expansion slot, using the retention device for instance, a screw or lever supplied with your computer. Ensure that the positive lead of the LED cable usually Adaptec RAID 6805Q PCI-E Adapter red wire or a wire marked with a red stripe is attached to pin Series 6 controllers only Optionally, connect your RAID controller's I2C connector not available on all models to an I2C connector on an internal backplane or enclosure, using an I2C cable.

If you are not installing internal disk drives, close your computer cabinet, reattach the power cord, then continue with Connecting External Devices on page Installing a RAID Controller with Zero Maintenance Cache Protection Microsemi Adaptec RAID controllers with zero maintenance cache protection include a flash module daughterboard and a supercapacitor module. On Microsemi Adaptec Series Q controllers, the daughterboard is pre-installed.

HP SCSI Devices

The supercapacitor module is always user installed. It assumes that the daughterboard is already installed.

Microsemi Adaptec Series 6Q controllers do not include a mounting plate for the supercapacitor module. You must affix the supercapacitor to the computer chassis with cable ties. For controllers with optional zero maintenance cache protection non-q controllersrefer to the AFM Installation Guide for details about installing the daughterboard on the controller.

DOWNLOAD DRIVERS: ADAPTEC RAID 6805Q PCI-E ADAPTER

Do NOT remove or insert a fully charged supercapacitor module. Always discharge the unit first to avoid damage to the controller or flash backup module.

ADAPTEC RAID 6805Q PCI-E ADAPTER WINDOWS 8 DRIVER DOWNLOAD

The factory ships with discharged units, so they are safe to install when Adaptec RAID 6805Q PCI-E Adapter receive them. To ensure that an installed unit is discharged, switch your system OFF, then wait 5 minutes. After a dirty shutdown, wait 3 minutes after backup is complete, then remove the unit. Assemble the mounting plate and attach the supercapacitor module: The full-height bracket is installed on the front side of the mounting plate the side with the bentswith the mounting screws inserted from the back, as shown in the figure below.

Be sure Adaptec RAID 6805Q PCI-E Adapter attach the mounting plate to the bracket with recessed side at the bottom! Attach the mounting clip to the front of the mounting plate with four 4 Phillips screws. The large friction clip should face the front of the mounting plate. Large friction clip Recessed side Mounting clip b Insert the supercapacitor module into the mounting clip. The supercapacitor module snaps securely into place between the large and small friction clips, as shown in the figure below. Be sure to orient the supercapacitor module such that the connecting cable faces the rear of the mounting plate. Select an available PCIe expansion slot that's compatible with your RAID controller and remove the slot cover, as shown in the figure below.

Be sure to choose a Adaptec RAID 6805Q PCI-E Adapter in the backplane with an empty slot next to it; you will use the empty slot to install the supercapacitor mounting plate, after you install the controller. Remove the slot cover for the mounting plate, then continue with the next step.

Serial Attached SCSI RAID Controllers - PDF

Attach the supercapacitor module to the RAID controller by inserting the connector into the socket on the flash module daughterboard, as shown in the figure below. The connector attaches to the socket in only one direction.

Use the included extender cable if you need extra length to reach the connector on the daughterboard. Extender cable 6. Install the mounting plate in the empty slot next to the controller, as shown in the next figure. After securing the mounting plate to the card cage, verify that the supercapacitor module and mounting plate sit above and do not touch Adaptec RAID 6805Q PCI-E Adapter PCIe slot. Prepare and install your internal disk drives, following the instructions in Connecting Disk Drives to Your Controllers on page If you are not installing internal disk drives, close your computer cabinet, reattach the power cord, then continue with Connecting External Devices on page Restart your computer.

The supercapacitor starts charging automatically. It should reach full charge in minutes.

96RC-SAS-8P-PE-AD - Adaptec SAS 8 Port 6GB/S PCIEX8 - Advantech

See for a list of compatible drives. There are no jumpers or switches to set before installation. If you plan to build a bootable array, ensure that Adaptec RAID 6805Q PCI-E Adapter install at least the minimum number disk drives required to support the RAID level you want. See What is SAS?

You have two connection options: Read caching is improved with maxCache 2. To deliver the advanced performance capabilities of SSD caching to a broader set of application workloads, maxCache 2.

Compatibility, Reliability, and Support Adaptec Series Q has been extensively tested with third-party components to deliver the utmost in compatibility. Microsemi Adaptec RAID ZQ 12 Gbps PCIe Gen3 SAS/SATA RAID adapter with 16 internal native ports and LP/MD2 form. Adaptec RAID Q. Adaptec RAID TQ Adaptec RAID TQ. 6Gb/s PCIe Gen2 SAS/SATA RAID adapter with 8 internal top-mounted ports and Adaptec RAID Q.
